PVC Sealing machine

PM 400L IMPULSE HAND SEALER

Sr. No   Specifications
1. Type :  double sealing tongs for durable & perfect sealing
2. Width of weld: weld width of 10mm
3 Length of weld : Length of sealing around 400mm
4. Weight of tongs : Around 2 kg.
5. Tong closure/ opening Automatic magnetic closure with press of a button. Continuous hold should not be required. Automatic opening after sealing.

PM 400L IMPULSE HAND SEALER





Sr. No   Specifications
1. Type :  double sealing tongs for durable & perfect sealing
2. Width of weld: weld width of 10mm
3 Length of weld : Length of sealing around 400mm
4. Weight of tongs : Around 2 kg.
5. Tong closure/ opening Automatic magnetic closure with press of a button. Continuous hold should not be required. Automatic opening after sealing.
6 Controls Touch  screen
7 Settings Micro controller based system to store various options for sealing different gauge/ types of material
8. Electrical connection 220/ 240VAC : 50/60 Hz
9. Power rating Upto 5 kW
10. Cable length 2 meter with a suitable connector
11. Vibration level of the unit NO Vibration
12 Guarantee Period One year
13 Electrical unit Should have a smooth SS 304 outer body with touch screen display in front
14 Dimensions of electrical unit 10 inch  (H) x 16 inch (L)  x 7 inch (W)
14 The weld holding time and the cooling time delay should be managed by electronic controller
15 The electronic controller should have audio and visual alarm of weld and cooling time
16 The electronic controller should have predefined setting for sealing of material having different thickness
17 the unit is mounted on a trolley,  well supported with good stability  & very good movement
